Table 4.4.8.3-1 SIP CO ATTRIBUTES
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
P-Asserted-ID
Display
The “Display” field of the “P-Asserted ID” header can be
configured to use the below:
 System Rule:
- a. P-Asserted ID = Extension, display Contact Display
Name from PGM 126, otherwise display Station Name
from PGM 111 or blank.
- b. P-Asserted = Original CLI, display Station Name from
PGM 111 for ICM call or the Name in received by the
system for the original outside call.
- c. P-Asserted = Fixed Table display Contact Display
Name from PGM 126 or blank.
 Original CLI: the CLI received by the system for the original
incoming call.
Refer to
description
SYS RULE
Remote-Party-
ID
The Id in the “Remote Party Id” header of SIP messages employ.
The Station CLI, the original CLI, or a fixed User ID.
 Extension: the Extension SIP User ID or Extension
Outgoing CLII as assigned for the From ID under ID
Individuality.
 Original CLI: the CLI received by the system for the original
incoming call or station number for the ICM call.
 Fixed Table: the SIP User ID from the SIP UID Fixed Table
Index attribute is assigned below.
Refer to
description
Extension
Diversion
The Id in the “Diversion” header of SIP messages can be based
on the calling station, the Original CLI, a fixed User ID, or Unused.
 Unused: no Diversion header provided.
 Extension: the Extension SIP User ID or Extension
Outgoing CLII as assigned for the From ID under ID
Individuality.
 Original CLI: the CLI received by the system for the original
incoming call or the station number for the ICM call.
 Fixed Table: the SIP User Id from the SIP UID Fixed Table
Index attribute assigned below.
Refer to
description
Unused
SIP UID Assignment
SIP User ID
Fixed Table
Index
When a header is assigned to use “Fixed Table,” the ID from this
SIP User ID (PGM 126) Table index is used.
Index
SIP User ID
SELECTION
When a header is assigned to use the “Extension SIP-User-ID
Table,” the SIP User ID is selected using this SIP UID index in the
Station Attributes (PGM 111).
Index,
Index 2,
Index 3
SIP User
Table Index
External CODEC Priority Configuration
1st ~5th priority
1st. Priority, 2nd. Priority, 3rd. Priority, 4th. Priority, 5th. Priority,
If It specifies priority to a specific CODEC, then it will work for
negotiation RTP data. If the only 1st. priority is specified, and the
others are none, then it will work as single CODEC only does
None/ g.711-u/ g.711-a/ g.723.1/ g.729/ g.729-a/ g.722
Refer to
description
none
