iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
272
Table 4.4.8.6-1 SIP User ID ATTRIBUTES
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
DID Conversion
Type
When the Ring Route above is defined as DID, the system will
send the call to a destination based on the DID conversion
selected here. The digits in the SIP User ID may be used “as is”
to identify the desired station, modified based on the DID Digit
mask below and routed to the resulting station, or the modified
DID number can be used as an index to the Flexible DID
Conversion Table, PGM 231 to route the call.
 DID Digit Conversion,
 Use ‘as is,’
 Modify Using Flexible DID Conversion Table
Refer to
description
Use ‘as is’
Number of Digits
(2-4) Expected
from DID Circuit
When DID Digit Conversion or Flexible DID Conversion Table
routing is used, the number of digits received is defined in this
field.
eMG80/100: 3, eMG800:4 , UCP: 4
2-4
Refer to
description
DID Digit Mask
When DID Digit Conversion or Flexible DID Conversion Table
routing is used, the digit conversion is defined in this field. For
each of the four (4) digits, use “*” to accept any digit, “#” to
delete the digit, or a digit 0-9 to replace the digit.
eMG80/100: #***, eMG800: ****, UCP: ****
4 Digits: *,
#, 0-9
Refer to
description
SMS Received
Station Number
When an SMS is received for this User Id, the SMS's station
must be defined.
