iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
281
For what?
Re-Registration Timer
It will be useless if [SIP User ID Attributes (PGM 126) - Registration Timer Usage] is ON
SIP Extension’s Local UDP/TCP/TLS Port number
Proxy Port
Server port number insight of SIP Extension toward MPB/UCP
Transport
Signaling mode
SIP Extension’s CODEC Priority
NTP Server and DST setting
The default volume of Speaker/Handset/Headset, the maximum volume of Handset
Table 4.4.8.8-1 SIP PHONE PROVISIONING
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
CONFTYPE
To modify or view a Configuration file, select an Ericsson-LG
Enterprise SIP Phone type from the drop-down.
None
MAC address must just be entered for Private Conf file
Private MAC
There are two types of Config files, a global file for all
phones of a specific type and a phone-specific file. To view
or modify a Phone specific file, enter the MAC address of
the SIP phone.
Private MAC
address
Don’t enter MAC address for common Conf file
Registration
Timer
When the SIP User ID Attributes are configured with
Registration Mode=Register and the Registration Timer
Usage=OFF, this timer is used to determine the valid
registration period.
120-3600
3600
Local UDP Port
When employing UDP transport, this port number is
employed for messages from the SIP phone.
Port (1-
65535)
5060
Local TCP Port
When employing TCP transport, this port number is
employed for messages from the SIP phone.
Port (1-
65535)
5060
Local TLS Port
When employing TLS transport, this port number is
employed for messages from the SIP phone.
Port (1-
65535)
5061
Local RTP Port
The system sends RTP packets to the SIP phone using the
first port available, starting with this port number.
Port (1-
65535)
23000
Proxy TCP Port
The SIP phone will send messages to the system over this
SIP Server port.
Port (1-
65535)
5060
Proxy TLS Port
The SIP phone will send messages to the system over this
SIP Server port.
Port (1-
65535)
5061
Transport Mode
The IP packet transport mode used between the system and
SIP phone for signaling messages is defined as UDP, TCP,
or TLS. In the case of TLS, the options configured in the SIP
Common Attributes (PGM 210) apply.
UPD
TCP
TLS
UDP
