iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
35
Table C-4 BOARD DATA
BTN
SUB-MENU
RANGE
DEFAULT
REMARK
PGM: 130 - H.323 VoIP Attributes
1
H.323 Setup Mode
0~1
Fast
0: Fast/1: Normal
2
H.323 Tunneling Mode
1: ON, 0: OFF
ON
0:Off/1:On
3
H.323 DTMF Path
0~1
0: In-band
1:Out/0:In
4
H.323 DiffServ Pre tagging
00~63
4
5
RAS Usage
1: ON, 0: OFF
OFF
6
RAS Multi-cast IP Address
IP address
224.0.1.41
7
RAS Multi-cast IP port
Port number
1718
8
RAS Uni-cast IP Address
IP address
82.134.80.2
9
RAS Uni-cast IP port
Port number
1719
10
RAS Keep-alive Timer
001 ~ 999
120
1 second increments
11
RAS Numbering Plan prefix
24 digits
12
RAS Gateway Id
128 characters
Web Admin only
13
RAS Light RRQ
1: ON, 0: OFF
OFF
14
TCP Keep Alive
1: ON, 0: OFF
ON
15
Failover Usage
1: ON, 0: OFF
OFF
16
Failover Time
03-10 (Sec.)
5
17
Failover Group
01-21
18
Q931 START PORT
00001-65535
2048
19
Q931 END PORT
00001-65535
2559
20
H245 START PORT
00001-65535
2560
21
H245 END PORT
00001-65535
3071
22
RAS START PORT
00001-65535
2048
23
RAS END PORT
00001-65535
3071
24
H.323 VoIP Attributes
24-1
MEDIA START PORT
00001-65535
6000
24-2
MEDIA END PORT
00001-65535
7036
24-3
DATA START PORT
00001-65535
8500
24-4
DATA END PORT
00001-65535
8548
PGM: 131 -T1/E1/PRI Attributes
1
T1 Setup Mode
0~1
D4
0:D4/1:ESF
2
T1 Line Mode
0~1
B8ZS
0: B8ZS/1:AMI
3
PRI Line Mode
0~1
TE
0:NT/1:TE
4
PRI/E1 CRC Check
1: ON, 0: OFF
OFF
5
E1 R2 DSP Check
1: ON, 0: OFF
OFF
6
DCO PX Type
1: S1240
2: TDX1B
3: STANDARD
4: CONGES_DIS
STANDARD
PGM: 132 - Board Base Attributes
1
Router IP address
IP Address
2
Device CODEC Type
0-4
4
0: G.711,
