iPECS UCP600 - Page 477

iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
36
Table C-4 BOARD DATA
BTN
SUB-MENU
RANGE
DEFAULT
REMARK
1: G.723.1,
2: G.729,
3: G.722
4: System Codec refer to
PGM 161-button 9.
3
Firewall IP address
IP Address
4
RTP Security
1: ON, 0: OFF
ON
5
TNET Enable
1: ON, 0: OFF
OFF
6
UMS Sender e-mail address
40 Characters
Web-only to modify
7
T38 Enable
1: ON, 0: OFF
OFF
8
USE Board IP for SIP
1: ON, 0: OFF
OFF
9
RTP firewall IP
IP address
10
T38 Port Usage
0: DIFF WITH
VOICE
1: SAME AS
VOICE
2:TRIGGERING
0
11
RFC2833 Payload
000-127
0
12
RFC2833 Volume
00-36
0
-dB
13
RFC2833 Redundancy
1-8
0
Table C-5 CO LINE DATA
BTN
SUB-MENU
RANGE
DEFAULT
REMARK
PGM: 140 - CO Service Attributes
CO Service Type
Flex 1~4
1 (Normal)
1: Normal CO line, 2: DID,
3: TIE Line,4: Unused
PGM: 141 - CO/IP Line Attributes I
1
CO/IP Group Assignment
01-20
2
CO Line COS
1~5
1
3
CO Start Signal
1: Ground, 0: Loop
Loop
4
CO Line Type
1: PBX, 0: CO
CO
5
CO Line Signal Type
1: DTMF, 0: Pulse
DTMF
6
Flash Type
1: Ground, 0: Loop
Loop
7
Universal Night Answer
1: ON, 0: OFF
OFF
8
CO/IP Group Auth
1: ON, 0: OFF
OFF
9
Data Station No
4 digits
FAX/Modem can be assigned
to STA
10
Tenancy Group
00~ 15
00
11
CO VoIP Mode
1 ~ 6
Common
1: Common, 2: H.323 only, 3:
SIP only, 4: RTP RLY, 5:
H.323/TRP RLY, 6: SIP/RTP
RLY
