iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
79
Table 3.3.2.2-1 DEVICE& STATION ADDRESS PLAN (PGM 103)
BTN
DISPLAY
FEATURE
DEFAULT
1
001-001 :B40EDCBF5606
VOIP 1 :10 .10 .10 .2
Line 1 - Sequence Number, 2 or 3 digits
MAC Address, 12 digits
Line 2 - Module Type, 4 characters First
Logical port number IP Address, 7~12 digits
CO & VoIP board
IP address set
sequentially from
the range in PGM
102.
1–1
SET IP ADDRESS
VOIP 1 : 10.10.10.2
Use Flex button 1 to set the device‘s IP
address in IP v4 format.
10.10.10.10~254
1–2
SET MAC ADDRESS
001-001 : B40EDCBF5606
Use Flex button 2 to enter the device‘s MAC
address in the system memory.
None
1–3
ARP
(1:ON/0:OFF): OFF
Use Flex button 3 to enable/disable Direct
Send mode, which employs layer 2
switchings to local devices.
OFF
1–4
REGISTRATION
(0:UCAST/1:MCAST): MCAST
Use Flex button 4 to enable/disable Local
Device Mode, which defines the device as a
common LAN with the PB.
MCAST
1–5
CPU TYPE
MSC1K
Flex button 5 displays the type of CPU
employed in the device.
1–6
DEVICE(BOARD) ID
PRIB
Flex button 6 displays the Board type
designation.
2
001-001 : B40EDCBF5606
KTU 100 :10.10.10.10
LCD shows:
Line 1 Sequence Number, 3 digits MAC
Address, 12 digits
Line 2 Station Type, 3 characters Station
Number, 2~4 digits IP Address, 7~12 digits
Station IP
address set
sequentially, from
the range in PGM
102.
2–1
SET IP ADDRESS
KTU 100 :10.10.10.10
Use Flex button 1 to set the device‘s IP
address in IP v4 format.
10.10.10.10~254
2–2
SET MAC ADDRESS
001-001 : B40EDCBF5606
Use Flex 2 button to enter the device‘s MAC
address into system memory.
None
2–3
ARP
(1:ON/0:OFF): OFF
Use Flex button 3 to enable/disable Direct
Send mode, which employs layer 2
switchings to local devices.
OFF
2–4
REGISTRATION
(0:UCAST/1:MCAST): MCAST
Use Flex button 4 to enable/disable Local
Device Mode, which defines the device as on
a common LAN with the MPB.
MCAST
