iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
80
Table 3.3.2.2-1 DEVICE& STATION ADDRESS PLAN (PGM 103)
BTN
DISPLAY
FEATURE
DEFAULT
2–5
CPU TYPE
MSC1K
Flex button 5 displays the type of CPU
employed in the device.
2–6
DEVICE(BOARD) ID
HYIB
Flex button 6 displays the terminal type
designation.
3
001-017 : B40EDCBF5606
MISU :10.10.10.2
LCD shows:
Line 1 Sequence Number, 2 digits MAC
Address, 12 digits Line 2 “MISU” IP Address,
7~12 digits.
IP address of
MISU.
Functions in the
system‘s MPB set
automatically,
3–1
SET IP ADDRESS
MISU :10.10.10.2
Use Flex button 1 to set the device‘s IP
address in IP v4 format.
10.10.10.10~254
3–2
SET MAC ADDRESS
001-003 : B40EDCBF5606
Use Flex button 2 to enter the device‘s MAC
address into system memory.
None
3–3
ARP
(1:ON/0:OFF): OFF
Use Flex button 3 to enable/disable Direct
Send mode, which employs layer 2
switchings to local devices.
OFF
3–4
REGISTRATION
(0:UCAST/1:MCAST): MCAST
Use Flex button 4 to enable/disable Local
Device Mode, which defines the device as a
common LAN with the MPB.
MCAST
3–5
CPU TYPE
MSC1K
Flex button 5 displays the type of CPU
employed in the device.
3–6
DEVICE(BOARD) ID
MISU
Flex button 6 displays the MISU type
designation.
4
001-015 : B40EDCBF5606
VMIU :10.10.10.2
LCD shows:
Line 1 Sequence Number, 2 digits MAC
Address, 12 digits Line 2 device type and IP
address.
.
4–1
SET IP ADDRESS
VMIU :10.10.10.2
Use Flex button 1 to set the device‘s IP
address in IP v4 format.
10.10.10.10~254
4–2
SET MAC ADDRESS
001-015 : B40EDCBF5606
Use Flex button 2 to enter the device‘s MAC
address into system memory.
None
