iPECS UCP600 - Page 523

iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
82
Table 3.3.2.2-1 DEVICE& STATION ADDRESS PLAN (PGM 103)
BTN
DISPLAY
FEATURE
DEFAULT
7–1
SET IP ADDRESS
WTIB :10.10.10.14
Use Flex button 1 to set the device‘s IP
address in IP v4 format.
10.10.10.10~254
7–2
SET MAC ADDRESS
001-003 : 00405A142C67
Use Flex button 2 to enter the device‘s MAC
address into system memory.
None
7–3
ARP
(0:ON/1:OFF): OFF
Use Flex button 3 to enable/disable ARP,
ARP OFF enables Direct Send, which
employs layer 2 switching to local devices.
OFF
7–4
REGISTRATION
(0:UCAST/1:MCAST):MCAST
Use Flex button 4 to disable/enable Local
Device Mode, which defines the device as on
a common LAN with the system. MCAST
enables Local Device Mode.
MCAST
7–5
CPU TYPE
MS828
Flex button 5 displays the type of CPU
employed in the device.
7–6
DEVICE(BOARD) ID
WTIB
Flex button 6 displays the type designation,
WTIB.
