iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
83
4.3.2.3 CO Device Sequence Number -PGM 104
The system uses the Sequence Number to assign logical (software) port numbers. This Sequence Number
relates the hardware and software port numbers for each device.
001 002 003 004 005 006
009 007 008 013 014 . . .
Press the [PGM] button and dial 104.
Press the Flex button (1~6) for the desired Sequence Number, use
the [VOL UP] and [VOL DOWN] buttons for the next/previous set of
six Sequence Numbers.
Using the dial pad, enter new slot numbers. Note slot numbers
cannot be duplicated, and duplicates will cause an error. The
[SPEED] button may be used to erase the slot number associated
with the selected Sequence Number.
Press the [Save] button to store the new Slot data.
4.3.2.4 Flexible Station Numbering Plan -PGM 105
Each LDP Phone, iPECS IP Phone, and SLT is assigned a Sequence Number during the registration process.
The station Sequence Number is a 3-digit number starting at 001, which is incremented as each terminal
device is registered.
At registration, station numbers increment sequentially with the Sequence Number and are assigned starting
at station 100 for Sequence Number 001.
The Station Numbering Plan allows the station numbers to be Three (3) to eight (8) digits in length.
001 002 003 004
100 101 102 103
Press the [PGM] button and dial 105.
Use either of the two methods below to change the station number
associated with a Sequence Number. Note pressing the [SPEED]
button twice clears all station number assignments.
The [VOL UP] / [VOL DOWN] buttons are used to view the
next/previous 2 station Sequence Numbers.
Range entry:
Using the dial-pad, enter a station number range (first & last station
number). The two station numbers must be of the same length, 2~8
digits. The range assignment begins with the first station number
shown by the LCD and continues to the end of the entered range.
Single entry:
4.1 Press the Flex button 1~4 to select the desired Sequence Number
from the two shown by the LCD.
4.2 Dial new station number.
Press the [Save] button to store the new station numbers.
