iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
101
Table 3.3.3.2-3 STATION ATTRIBUTES III (PGM 113)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
24-7
100-110 BARGE IN MODE
(0-2) : DISABLE
Barge permits an authorized extension to
intrude into another existing outside/internal
call or to disconnect an existing call forcedly.
 0: Disable- Barge In is disabled.
 1: Monitor- Barge In monitors other
conversations.
 2:Monitor&Join & Disconnect - Barge In
monitors join and Forced Disconnect.
Refer to
description
Disable
24-8
100 – 110 SLT FLASH
MODE
(0-3) : FLASH TRANSFER
SLT Flash works as followingoption.
 0: Flash Transfer– Flashdetected, the
line is held and the line goes to the
waiting state.
 1: Flash Drop - Flash detected, and Line
is disconnected.
 2: Flash Ignore– Flashdetected, but
Ignored.
 3: Hold Release– Flashdetected, then
the line is held, and the line goes to
waiting state. And the SLT user goes
on-hook, then the held line is
disconnected, not recalling.
Refer to
description
Transfer
24-9
100 – 110 RLS COST DISP
(1:ON/0:OFF) : OFF
When CO line is released,according to admin
option,call-cost or disconnection-causecan
be displayed to user LCD.
0 : OFF
1 : ON
OFF
24-10
100 – 110 LDT TBL INDEX
(00-10) : 01
LCR will be operated with thisLDT table
index
Number of
LDT Table
1
24-11
100 – 110 WEB CALL BACK
(1:EN/0:DIS) : DISABLE
Enable Web call back service. When
enabled, call back service on station web
admin could be used.
0: Disable
1: Enable
Disable
24-12
100 – 110 VSF SMTP SECU
(0-2) : NO SECURITY
Security for VSF mail sending can choose.
0: No Security, 1: SSL, 2: TSL
Refer to
description
NoSecurit
y
24-13
100 – 110 VSF SMTP PORT
(00001-65535) : 00025
When VSF mail sending, SMTPport can be
program.
00001 –
65535
25
24-14
100–110 VSF S-MAILADDR
…………………………
When VSF mail sending, SenderMail
Address can be program.
24-15
100 – 110 PREPAID CALL
(1:ON/0:OFF) : OFF
Enable prepaid call service.
0: OFF
1: ON
OFF
