iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
103
4.3.3.3 Station Attributes IV -PGM 114
When a station uses an ISDN Line, various parameters relating to ISDN Calling Line Identification and
Connected Line Identification can be assigned for each station.
In addition, when the station is an SLT, several parameters must be set to indicate the capabilities related to
the station, such as 3.1 KHz audio for ISDN use. Refer to Table 3.3.3.3-1 for a description of the attributes and
the inputs available.
PROCEDURE
STATION ATT 4
ENTER STA RANGE
Press the [PGM] button and dial 114.
100-110 STATION ATT4
PRESS FLEX_KEY (01-24)
Use the dial-pad to enter a station range (Ex. 100~110). For a single
station, enter the same number twice.
Press the desired Flex button; refer to Table 3.3.3.3-1.
Use the dial-pad to enter desired data for the attribute. Refer to Table
3.3.3.3-1.
Press the [Save] button to store the data entry.
Table 3.3.3.3-1 STATION ISDN ATTRIBUTES (PGM 114)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
100-110 CLIP DISPLAY
(1:ON/0:OFF ) : OFF
CLIP (Calling Line Identification
Presentation), an ISDN service, sends the
calling party's number to the system in the
call SETUP message. If enabled here, the
number will be shown in the iPECS Phone
LCD.
0: OFF
1: ON
OFF
2
100-110 COLP DISPLAY
(1:ON/0:OFF ) : OFF
COLP (Connected Line Id Presentation), an
ISDN service, sends the number of the
answering party to the system in the call
CONNECT message. If enabled here, the
number will be shown in the iPECS Phone
LCD.
0: OFF
1: ON
OFF
3
100-110 PROGRESS IND
(1:ON/0:OFF ) : OFF
When employing a non-ISDN terminal,
specifically a modem or analog FAX, the
ISDN call SETUP message must include
this message, and the Progress Indication
parameter should be set to “ON.”
0: OFF
1: ON
OFF
4
100-11- CLIR SERVICE
(1:ON/0:OFF ) : OFF
CLIR (Calling Line Identification
Restriction), an ISDN service, removes the
calling party Id sent from the PSTN to the
called party with a RESTRICT instruction in
the SETUP message.
If enabled here, the system will send the
RESTRICT instruction to the PSTN when
an outgoing ISDN call is placed.
0: OFF
1: ON
OFF
