iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
104
Table 3.3.3.3-1 STATION ISDN ATTRIBUTES (PGM 114)
100-110 COLR SERVICE
(1:ON/0:OFF ) : OFF
COLR (Connected Line Id Restriction), an
ISDN service, removes connected party Id
sent from the PSTN to the calling party with
a RESTRICT instruction in the CONNECT
message.
If enabled here, the system will send the
restricted instruction to the PSTN when the
station answers an ISDN call.
When not restricted (button 4 & 5 above)
and entry 00 of the CLIP/CLOP Table is
selected in PGM 143-button 1& 2, this entry
is added to the number sent in the ISDN
call SETUP or CONNECT message in
place of the station number.
100-110 3.1 kHz AUDIO
(1:ON/0:OFF ) : OFF
When an analog device (SLT or FAX) uses
an ISDN Line in the system, the Information
Element of the ISDN SETUP message
must indicate it only has 3.1 KHz audio
capabilities. If an SLT or analog FAX is
allowed access to the ISDN Lines, this
parameter must be “ON.”
100-110 CLI NAME DISP
(1:ON/0:OFF ) : OFF
When the CLI data from the PSTN in the
call SETUP message matches a number in
Speed Dial, the system can display the
name associated with the Speed Dial bin is
set to ON.
100-110 CLI/REDIRECT
(1:RED/0:CLI) : CLI
When the ISDN redirects an incoming ISDN
call, the call SETUP message will contain
an original and redirected CLI. This
selection determines if the iPECS Phone
will display the original or redirected
number.
100-110 CLI MSG-WAIT
(1:ON/0:OFF ) : OFF
A log of caller identification can be
maintained for the user, permitting the user
to call back the identified party.
System-wide, up to 1000 entries can be
maintained in the log.
100-110 EXTOR ATD
(1:ATD/0:EXT ) : EXT
When the system sends a station number
with CLIP orCOLP, the number can be
either the Attendant number or the number
of the station.
