Table 3.3.4.1-1 H.323 VOIP ATTRIBUTES (PGM 130)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
7
RAS MULTICAST PORT
(00001-65535): 01718
Multi-cast IP Port for RAS Information of
Gatekeeper.
IP Port #
1718
8
RAS UNICAST IP
82.134.80.2
Uni-cast IP address for RAS Information
of Gatekeeper.
IP Address
82.134.80.
2
9
RAS UNICAST PORT
(00001-65535): 01719
Uni-cast IP Port for RAS Information of
Gatekeeper.
IP Port #
1719
10
RAS KEEP_ALIVE TM
(001-999) : 120 (sec)
The time between exchange of RAS
Information between GK and
VOIB/VOIU.
001-999
(SEC)
120
11
RAS NUM PLAN PREFIX
9
The numbering plan for Calling Numbers
in RAS Setup.
Number
(24 digits)
9
12
RAS GATEWAY ID
ONLY POSSIBLE BY WEB ADM
The Gatekeeper ID (This can be
programmed only via WEB Admin).
128
Character
13
RAS LIGHT RRQ
(1:ON/0:OFF) : OFF
The system can be assigned to use the
simple RRQ (Registration Request)
message (ON) or the full RRQ message
(OFF).
0: OFF
1: ON
OFF
14
TCP KEEP ALIVE
(1:ON/0:OFF) : ON
The system will send a polling message
every 75 seconds to assure the status of
the TCP connection.
0: OFF
1: ON
ON
15
FAIL OVER USAGE
(1:ON/0:OFF) : OFF
The H.323 call will be failover to another
line (FAIL OVER USAG: ON).
0: OFF
1: ON
OFF
16
FAIL OVER TIME(sec)
(03-10) : 05
The H.323 call will be failover. The time
will be set.
03-10
(Sec.)
5
17
FAIL OVER CO GRP
(01-21) : . .
If the H.323 call is failover, assign
another CO group.
01-21
18
Q931 START PORT
(00001-65535) : 02048
IP-Binding H.323 signaling option: Q.931
TCP Start Port in case of outgoing call.
00001-
65535
2048
19
Q931 END PORT
(00001-65535) : 02559
IP-Binding H.323 signaling option: Q.931
TCP End port in case of outgoing call.
00001-
65535
2559
