Table 3.3.4.1-1 H.323 VOIP ATTRIBUTES (PGM 130)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
20
H245 START PORT
(00001-65535) : 02560
P-Binding H.323 signaling option: H.245
TCP Start Port.
00001-
65535
2560
21
H245 END PORT
(00001-65535) : 03071
IP-Binding H.323 signaling option: H.245
TCP End Port.
00001-
65535
3071
22
RAS START PORT
(00001-65535) : 02048
IP-Binding H.323 signaling option: RAS
UDP Start Port.
00001-
65535
2048
23
RAS END PORT
(00001-65535) : 03071
IP-Binding H.323 signaling option: RAS
UDP End Port.
00001-
65535
3071
24
001 H323 VOIP ATTR (2ND)
PRESS FLEX KEY (1-4)
24-1
MEDIA START PORT
(00001-65535) : 06000
IP-Binding media option: Media UDP
Start Port.
00001-
65535
6000
24-2
MEDIA END PORT
(00001-65535) : 07036
IP-Binding media option: Media UDP
End Port.
00001-
65535
7036
24-3
DATA START PORT
(00001-65535) : 08500
IP-Binding option: Data Sharing TCP
Start Port.
00001-
65535
8500
24-4
DATA END PORT
(00001-65535) : 08548
IP-Binding option: Data Sharing TCP
End Port.
00001-
65535
8548
24-5
H.245 SETUP
(1:ON/0:OFF) : OFF
This feature is the ability of two user
endpoints to communicate before call is
actually established in normal call mode.
This feature is not used when 'H323
Setup Mode' is 'Fast'.
Setup: Caller party tries to open early
media on receiving the Setup message.
Proceeding: Calling party tries to open
early media on receiving the Proceeding
message.
Alerting: Calling party tries to open early
media on receiving the Alerting
message.
0: OFF
1: ON
OFF
24-6
H.245 PROCEEDING
(1:ON/0:OFF) : OFF
0: OFF
1: ON
OFF
24-7
H.245 ALERTING
(1:ON/0:OFF) : OFF
0: OFF
1: ON
OFF
