iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
131
4.3.4.3 Board Base Attributes – PGM 132
Appliances (Boards and IP Phones) can be connected to the iPECS over a managed WAN without employing
a VoIP channel.
In this case, the system does not implement security (IPSec) or QoS treatment over the link. To implement the
managed WAN connectivity, the iPECS must be assigned with the router's IP address for all appliances that
may attempt a point-to-point connection over the managed WAN, including devices on the iPECS LAN.
Note that if the device’s Router IP address is not defined, the system will use the Router IP address defined in
PGM 102.
The default codec employed by each device can be specifically defined as G.711, G.723, G.729, G.722, or the
system default codec PGM 161 can be defined. Note that the Sequence Number can be determined in PGM
103, Button 1.
PROCEDURE
BOARD BASE ATTRIBUTE
ENTER RANGE (001–300 )
Press the [PGM] button and dial 132, and enter Range (Ex. 001~002).
eMG800 range is 0001-2890.
001-002 BOARD ATTRIBUTE
PRESS FLEX KEY (01–13)
Use the dial pad to enter the Sequence Number range of the desired
module. Use PGM 103 to determine Sequence Numbers.
Press the desired Flex button; refer to Table 3.3.4.3-1.
Use the dial pad to enter the desired data. Refer to Table 3.3.4.3-1.
Press the [Save] button to store the Table data entry.
Table 3.3.4.3-1 BOARD ATTRIBUTES (PGM 132)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
001-002 ROUTER IP ADDR
0 .0 .0 .0
Enter the default Router IP address associated
with the selected devices.
0.0.0.0
2
001-002 DEV CODEC TYPE
(0-4): SYSTEM CODEC
Select the CODEC type for
theselecteddevices:
0: G.711,1: G.723.1,2: G.729,3: G.722
4: System Codec refer toPGM 161-button 9.
0-4
4
3
001-002 FIRWALL IP ADDR
0 .0 .0 .0
Enter the Firewall IP address associated with
the selected devices.
0.0.0.0
4
001-002 RTP SECURITY
(1:ON/0:OFF) : ON
Remote iPECS IP & LDP phones use IPSec to
assurea secure connection. To
reducebandwidth use, IPSec may bedisabled.
0: OFF
1: ON
ON
5
001-002 TNET ENABLE
(0:ON/0:OFF) : OFF
When a module or station is to be connected in
a Centralized, Control network (TNET), the
device must be enabled for TNET operation.
0: OFF
1: ON
OFF
6
001-002 VSF SENDER MAIL
. . . . . . . . . . . .
VMIU/VMIB e-mail address for
Mailbox Mail Sending.
NULL
