iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
147
4.3.5.7 CO Additional Attributes – PGM 148
CID Attributes are assigned for Analog CO Line Caller Id services.
PROCEDURE
CO ADDITIONAL ATTR
ENTER COL RANGE
Press the [PGM] button and dial 163.
01–02 CID SETTING
PRESS FLEX_KEY (01–13)
Use the dial–pad to enter a CO line range. For a single CO Line, enter the
same number twice.
Press the desired Flex button; refer to Table 3.3.5.7-1.
Use the dial–pad to enter desired data for the Attribute.
Press the [Save] button to store the data entry.
Table 4.3.5.7-1 CO Additional Attributes (PGM 148)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
01–02 CID MODE SELECT
(0–4) : FSK
CID signal type can be assigned
according to the CID type PSTN
provides.
0:Disabled, 1:FSK, 2 :DTAS FSK,
3:DTMF, 4:Russia CID
Refer to
description
FSK
2
01-02 RCID DETECT
(1: ALL/0: LOCAL) : ALL
Russia CID Detect Mode.
0: LOCAL
1: ALL
ALL
3
01-02 RCID REQUEST
(1: AUTO/0: USER) : AUTO
Russia CID Request Mode.
0: USER
1: AUTO
AUTO
4
01-02 RCID REQ TMR(10ms)
(010–150) : 030
Russia CID First Delay Timer.
010–150
(10msec)
030
5
01-02 RCID NOANS TMR(s)
(001–300) : 020
Russia CID NO–Answer Timer.
001–300
(sec)
020
6
01-02 RCID DGT NUMBER
(04–10) : 07
Russia CID Digit Number.
04–10
07
7
01-02 RCID REQ COUNT
(1–3) : 1
Russia CID Request Count.
1–3
1
8
01-02 RCID REQ DELAY
(10–30) : 10 (10ms)
Russia CID Retry Delay Timer.
10–30
(10msec)
10
