iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
154
Table 3.3.5.10-1 T1 LINE TIMERS (PGM 152)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
8
01-02 RELEASE
(000-127) : 007 (20ms)
For Ground Start Lines, defines the minimum
length of time ground will not be applied to
the TIP side from the PSTN.
0~127
(20 ms)
7
9
01-02 IASG TY
(1:DTMF/0:PULSE) : DTMF
Incoming Address Signaling Type defines the
type of signaling (DTMF or Pulse) expected.
0~1
DTMF
10
01-02 RING DTC
(2-9) : 2 (100ms)
The Ring DTC (detect) timer defines the
minimum acceptable length of the Ring-on
time during a ring cycle.
2~9
(100 ms)
2
11
01-02 RING STOP
(10-60) : 60 (100ms)
The Ring Stop timer defines the maximum
Ring-off time during a ring cycle.
10~60
(100 ms)
60
12
01-02 COLLECT DGT
(1-6) : 3
Collect DGT (digits) defines the number of
digits expected on a DID line.
1~6
3
13
01-02 STORE TIME
(01~15) : 15 (1sec)
For DID lines, this timer defines the
maximum delay between incoming DID
digits.
1~15
(second)
15
