4.3.5.11 DCOB CO Attribute – PGM 153
The DCOB Attributes defines various characteristics of the E1/PRI module when employing R2 signaling.
PROCEDURE
DCOB COLINE ATT
ENTER CO RANGE
Press the [PGM] button and dial 153.
01-02 DCOB CO ATT
PRESS FLEX KEY (1-6)
Use the dial-pad to enter a CO Line range (Ex. 01-02). For a single CO Line,
enter the same number twice.
Press the desired Flex button; refer to Table 3.3.5.11-1.
Use the dial-pad to enter desired data for the Attribute. Refer to Table
3.3.5.11-1.
Press the [Save] button to store the data entry.
Table 3.3.5.11-1 DCOB CO ATTRIBUTE (PGM 153)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
01-02 LINE STATUS
(1-9) : 6
Send Line status information to PX
when a call is routed to the subscriber
before the called party is ringing.
1~9
6
2
01-02 DNIS SERVICE
(1:ON/0:OFF) : OFF
In R2, determine whether system will
send caller information to PX or not.
0: OFF
1: ON
OFF
3
01-02 NO OF CLI DGTS
(01-15) : 10
In R2, board request CLI Digit to PX.
01~15
10
4
01-02 DCOB TYPE(0-2)
DID (2)
According to this type, the line can be
restricted to seize the CO line for the
outgoing call.
0: DID/DOD
1:DOD
2:DID
2
5
01-02 CALL CATEGORY
(1-9) : 1
In R2 signaling, the category signal
used by the iPECS is defined here.
1~9
1
6
01-02 DID DGT NUM
(00-32) : 00
Maximum number of DID digits if the
line is E1/R2
(if it is N/A, then it will follow PGM 145
3rd.)
00~32
0
