iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
184
4.3.6.15 Serial Port Function Selections – PGM 175
The system has an RS-232 serial port located on the MPB; Also, the system can employ IP over three (3) TCP
channels for the output of various system information.
Each output function is assigned a Serial port or TCP channel that is used to output the information. In
addition, a TCP port must be assigned when a function is defined to use a TCP channel.
The Serial port is located on the MPB; refer to the iPECS eMG Hardware Description and Installation
Manual. Note each function can be defined to use only one output. Refer to Table 3.3.6.15-1 and Table
3.3.6.15-2 for a description of the selections, the data entries required, and LCD displays.
PRINT PORT SELECTION
PRESS FLEX_KEY (1-2)
Press the [PGM] button and dial 175.
SELECT TCP NO
PRESS FLEX_KEY (1-9)
Press Flex button 1 to assign the output type for each function or Flex button
2 to assign the TCP port for the function when a TCP channel is selected for
the function.
Select the Flex button for the desired function. Refer to Table 3.3.6.15-1 or
Table 3.3.6.15-2.
Use the dial pad to enter the output type (Flex button 1) or TCP port (Flex
button 2). For Flex button 1 the entries available are:
- 1: Serial port 1
- 2: Serial port 2
- 3: TCP channel 1
- 4: TCP channel 2
- 5: TCP channel 3
- 6: USB COM1 (6)
- 7: USB COM2 (7)
Press the [Save] button to store the data entry.
Table 3.3.6.15-1 FUNCTION OUTPUT TYPE (PGM 175)
OFF LINE SMDR (1-7)
SERIAL1 (1)
Define the serial port or TCP channel used for
Offline SMDR/Statistics output.
ADMIN DATA (1-7)
SERIAL1 (1)
Define the serial port or TCP channel used for
the ADMIN Report output.
TRAFFIC (1-7)
SERIAL1 (1)
Define the serial port or TCP channel used for
the TRAFFIC report output.
Define the serial port or TCP channel used for
the SMDI output.
