Table 3.3.6.15-1 FUNCTION OUTPUT TYPE (PGM 175)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
5
CALL INFO (1-7)
SERIAL1 (1)
Define the serial port or TCP channel used to
receive Call Information output.
1 ~ 7
SERIAL1
6
ON-LINE SMDR (1-7)
SERIAL1 (1)
Define the serial port or TCP channel used for
the Online SMDR.
1 ~ 7
SERIAL1
7
TRACE (1-7)
SERIAL1 (1)
Define the serial port or TCP channel used for
the trace output.
1 ~ 7
SERIAL1
8
DEBUG (1-7)
SERIAL1 (1)
Define the serial port or TCP channel used for
the Debug output.
1 ~ 7
SERIAL1
9
ACD PACK (1-7)
SERIAL 1 (1)
Define the serial port or TCP channel used for
the Unified Messages.
1 ~ 7
SERIAL1
Table 3.3.6.15-2 OUTPUT FUNCTION TCP PORT (PGM 175)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
OFF-LINE SMDR (1-9999)
TCP PORT(NULL)
Define the TCP port used for Offline SMDR/
Statistics output.
1 ~ 9999
NULL
2
ADMIN DATA (1-9999)
TCP PORT(NULL)
Define the TCP port used for the ADMIN
Report output.
1 ~ 9999
NULL
3
TRAFFIC (1-9999)
TCP PORT(NULL)
Define the TCP port used for the TRAFFIC
report output.
1 ~ 9999
NULL
4
SMDI (1-9999)
TCP PORT(NULL)
Define the TCP port used for the SMDI output.
1 ~ 9999
NULL
5
CALL INFO (1-9999)
TCP PORT(NULL)
Define the TCP port used to receive Call
Information output.
1 ~ 9999
NULL
6
ON-LINE SMDR (1-9999)
TCP PORT(NULL)
Define the TCP port used for the On-line
SMDR.
1 ~ 9999
NULL
7
TRACE (1-9999)
TCP PORT(NULL)
Define the TCP port used for the trace output.
1 ~ 9999
NULL
