iPECS UCP600 - Page 630

iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
189
Table 3.3.6.17-1 SMDR ATTRIBUTES (PGM 177)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
23
PRINT SERIAL NO
(1: ON/0:OFF) : OFF
As part of SMDR output, the print record
number will reset to 1 when SMDR capacity
is reached, or SMDR records are deleted.
See button 18.
0: OFF
1: ON
OFF
24
SMDR ATTRIBUTRS(2ND)
PRESS FELX KEY (01-19)
01-19
24-1
SMDR HIDE DGT
1:RIGHT/0:LEFT) : RIGHT
When “HIDDEN DIALED DIGIT” is enabled,
button 8 above, this field determines if
leading or trailing digits are hidden.
0: Left
1: Right
Right
24-2
SMDR INTERFACE SVC
(0: OFF/1:CO/2:CO&ICM): 0
When enabled, the system stores SMDR
data to send to applications, including
NMS, upon request.
0: OFF
1: CO
2:CO&ICM
OFF
24-3
SMDR ICM SAVE
(1:ON/0:OFF) : OFF
When enabled, intercom call data is stored
as part of the SMDR data.
0: OFF
1: ON
OFF
24-4
SMDR ICM PRINT
(1:ON/0:OFF) : OFF
When enabled, intercom call data is printed
as part of the Online SMDR.
0: OFF
1: ON
OFF
24-5
SMDR DISC CAUSE
(1:ON/0:OFF) : OFF
When enabled, the disconnect cause is
stored in Offline SMDR data and printed as
parted of the Online SMDR.
0: OFF
1: ON
OFF
24-6
LONG TIME CALL (10min)
(000-144) : 000
To monitor long-time CO calls, a “Long
Time Call” can be set. 0 means no
monitoring. If CO call duration exceeds this
value, a notification will be sent to the NMS
server, displaying the alarm.
000 ~ 144
000
24-7
PRT LIMIT TO NET CALL
(1:ON/0:OFF) : OFF
When CO call is transferred to Net transit
out CO, it’s automatically deleted from
SMDR.
0: OFF
1: ON
OFF
24-8
INTERNATIONAL CODE
….
It is used to distinguish international calls
for SMDR.
4 digit
….
24-9
MOBILE PHONE CODE
….
It is used to distinguish mobile calls for
SMDR.
4 digit
….
24-10
SMTP MAIL SERVER ID
……………………………
This field defines the user’s ID for the
SMTP Mail server. If the user’s ID and
password are assigned, the SMTP Mail
server will check the validation of the user
ID and password.
Max 40
Chars
