iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
188
Table 3.3.6.17-1 SMDR ATTRIBUTES (PGM 177)
SMDR START TIMER (1sec)
(000 – 250) : 000
A “Valid call timer” can be set to allow for
call set-up times through the PSTN. A call
must be longer than the SMDR Start Timer
to generate a call record if enabled under
button 1 above.
SMTP IP ADDR (WEB)
0 .0 .0 . 0
SMTP Mail server IPv4 address to receive
the SMDR e-mail reports.
USER MAIL ADDR(WEB)
…………………………
User e-mail address to receive the SMDR
e-mail reports, display only. To change
data, use Web Admin.
MAIL SEND WEEKLY SET
N/A (0-7)
Sets day of the week to send SMDR data
weekly (0 for no weekly data, 1-7 for
Monday through Sunday)
MAIL SEND DAILY SET
00(00-23)
Sets time-of-day for SMDR data to be sent
daily (00for no daily records, 01-23 for an
hour of the day).
AUTO SEND MODE
(1 : ON/ 0: OFF) : OFF
If the SMDR buffer is full, the system can
automatically send a notification by e-mail.
AUTO DELETE MODE
(1 : ON/ 0: OFF) : OFF
Delete SMDR records after sending e-mail.
LONG DISTANCE CODE
0 .. .. .. ..
For SMDR and COS purposes, five (5)
Long Distance codes of up to two (2) digits
each can be assigned. If it is dialed as the
1st digit, the call is considered an LD call.
Flex button
1~5 +
digits 0~9
& ‘*’ as a
wild card
SMDR RIN/CLI/CPN SVC_I
(0:RIN/1:CLI/2:CPN):0
For incoming calls, the system will send the
defined data item for “Field I.” The data
item may be CLI, CPN, or Ring Service
Time. Note the User dialed number is
always provided for an outgoing call.
MSN PRINT ON SMDR
(1:ON/0:OFF) : OFF
Print MSN number Information in SMDR
Record.
SMDR RIN/CLI/CPN SVC_II
(0:RN/1:CL/2:CP/3:NO):2
For incoming calls, the system will send the
defined data item for “Field II.” The data
item may be CLI, CPN, or Ring Service
Time.
0: RING
1: CLI
2: CPN
3: None
To Next Page
