iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
209
Table 3.3.7.2-1 STATION GROUP— CIRCULAR & TERMINAL GROUPS (PGM 191)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
13
CIRC 401 MUSIC SRC
(00–37) : 01
A Music source is assigned so that calls to
the group receive audio from the source in
place of ring-back tone.
00: Ring-back,
01: INT Music,
02: EXT Music,
03: VSF MOH,
04~08: SLT MOH1~4,
09~37: VSF MOH2~30
Refer to
description
01
14
CIRC 401 MBR FORWARD
(1 : ON/ 0: OFF) : ON
A member activating Call forward may be
placed in an unavailable state for hunt group
calls (ON). When OFF, group calls are sent
to the member as normal.
0: OFF
1: ON
ON
15
MAILBOX MSG WAIT STA
. . . .
When a group calls overflows or routes to the
VM group, a station number is used to
identify the Mailbox for the Circular group
messages.
Station
….
16
MAILBOX PASSWORD
…………
The password associated with a group
Mailbox is defined here.
The password is used in conjunction with the
Circular group as with a normal station.
12 digits
….
17
CIRC 401 FORCED DEST
S/H/V/SPD (DIAL 1-4)
When a call is delivered to the group, the
system can redirect the call to the Forced
destination if enabled under button 18
below.1:Station, 2:Station group,
3:VSF Announce, 4:System speed
Refer to
description
-
18
FORCED FWD DESTUSAGE
(1:ON/0:OFF): OFF
Enables the system to redirect group calls to
the Forced destination defined under button
17 above.
0: OFF
1: ON
OFF
19
WAIT IF 1STANNC BUSY
(1:ON/0:OFF): ON
When a call assigned to receive an
announcement arrives and all channels are
busy, the call may wait with Ringback until a
channel is available (ON) or bypass the
announcement.
0: OFF
1: ON
ON
20
GROUP NAME
……………………………….
A hunt group name can be designated.
20
character
….
21
CIRC 401 MAX QUE C-CNT
(00-99) : 99
When the number of calls queued to the
group match this parameter, new calls will
receive an error tone and be disconnected
after the VSF AA announcement, if assigned,
is played.
00-99
99
