iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
229
4.3.8.7 Prefix Dialing Table – PGM 206
With this table, three features can be supported.
 CO Call charges with NPR metering.
 SIP direct dialing with no wait inter-digit timer.
 ISDN Prefix Call – ISDN en-block Dialing with Prefix Call Setup.
If first some digits (up to 8 digits) of outgoing dial number are matched with Prefix Code of each table, this
table can start work. By each CO-line (PGM 142 – F20), Table ID (0-6) can be set. This table ID (PGM 142 –
F20) is associated with PGM 206 – each table ID.
PROCEDURE
PREFIX DIALING TABLES
ENTER BIN NO (001-500)
Press the [PGM] button, dial 206, and enter the bin number (Ex.001).
PREFIX TABLE 001
PRESS FLEX KEY(01-10)
Use the dial-pad to enter the Table index number (bin).
Refer to Table 3.3.8.7-1
DISPLAY
Press the desired Flex button, refer to Table 3.3.8.7-1
Use the dial pad to enter desired data. Refer to Table 3.3.8.7-1.
Press the [Save] button to store the data entry.
Table 3.3.8.7-1 Prefix Dialing Table (PGM 206)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
001 PREFIX CODE
........
Enter the Prefix code. (Max 8 digits)
2
001 TABLE ID
(0 – 6) : 0
Enter Table ID (0-6). 0 means NOT used.
0-6
0
3
001 MIN DIGIT
(00 – 30) : 00
Select the minimum dial digits (00-30)
00-30
00
4
001 MAX DIGIT
(00 – 30) : 00
Select the minimum dial digits (00-30)
00-30
00
5
001 NUM OF TYPE(0-6)
UNKNOWN(0)
Select Number of Type (0~6).
 0:Unknown
 1:International
 2:National
 3:Network Spec
 4:Subscriber
 5:Abbreviated
 6:Reserved
Refer to
description
0
