4.3.8.6 PPP Attributes – PGM 205
In addition to remote access via an IP network connection, the system database may be accessed remotely
via MODU.
The system will request a user id and password, which must match one of the User Ids and passwords
assigned. After matching id and password are entered, the iPECS Home page is provided, and Web Admin is
available, as explained in section 4.
PROCEDURE
PPP ATTRIBUTES
PRESS FLEX KEY (1-7)
Press the [PGM] button and dial 205.
Press the desired Flex button; refer to Table 3.3.8.6-1.
Used the dial pad to enter desired data. Refer to Table 3.3.8.6-1 for
appropriate entries.
Press the [Save] button to store the data entry.
Table 3.3.8.6-1 PPP ATTRIBUTES (PGM 205)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
PPP DEST STA
….
Suppose the incoming capability is 64 Kbps
unrestricted digital, and the called party
number matches the PPP destination. In
that case, the system will automatically
answer the call and request a PPP ID and
password.
Station
number
None
2
PPP USER ID 1
likppp01
System accepts this PPP ID 1.
12Characte
r
likppp01
3
PPP PASSWORD 1
Ipkts01
The password entered is used to authorize
PPP ID 1.
12
Character
Ipkts01
4
PPP USER ID 2
likppp02
System accepts this PPP ID 2.
12
Character
likppp02
5
PPP PASSWORD 2
Ipkts02
The password entered is used to authorize
PPP ID 2.
12
Character
Ipkts02
6
PPP SERVER IP ADDR
10 .0 .0 .3
The operator can configure the PPP Server
IP Address with this option. The system
must be restarted to apply.
10.0.0.3
7
PPP CLIENT IP ADDR
10 .0 .0 .2
The operator can configure PPP Client IP
Address with this option. The system must
be restarted to apply.
10.0.0.2
