Table 4.4.2.2-1 Common Attributes
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
Tone/Ring Attributes
Call Time Tone
A tone can be sent periodically with indicating the elapsed time of
an outgoing CO/IP call. The Elapsed Call Timer determines the
period between tones. For more information about Elapsed Call
timer, refer to the title “System data: System timer (180~182,
186)”.
OFF
ON
OFF
Camp-on Tone
When the Camp-on feature is enabled for the station, the LCD
indicates the camped on-call if the station is busy and receives a
Camp-on request. If the Camp-on tone is enabled, the Camp-On
tone is sent to the station as an audible signal for the camp-on.
OFF
ON
ON
ICM Dial Tone
Source
One of four dial tone sources can be selected for each station.
Dial Tone / Internal music / External music /
VSF MOH / SLT MOH1~5 / VSF MOH2~30
Refer to
description
Dial Tone
ICM Ring Back
Tone Source
One of four ring-back tones can be selected for each station.
Ring Back Tone / Internal music/External music/VSF
MOH/SLT MOH1~5/VSF MOH2~30
Refer to
description
Ring Back
Tone
Off-hook ring
type
While the station is an Off-hook ring, the ring-type can be adjusted
as a single burst, muted normal ring, system ring, or no audible
ring signal.
BURST, MUTE, Refer to System Attributes, SILENCE
Refer to
description
Refer to
System
attributes
SIP color ring
With a SIP-based AA/VM that supports color ring, the color ring
may be provided to SIP phones. The group number associated
with the external AA/VM should be entered as the SIP Color Ring
source.
Station
number
Gain table
index
Selects one of three Tables to employ to set the gain from a
device to other device types. PGM 410 to 417 under the
Maintenance tab set the individual gains.
1-3
1
Tone table
index
Selects one of five Tables to determine the tones sent to the
Station. The individual tones are configured in PGM 410 to 417
under Maintenance.
1-5
1
Digit
conversion
table
One of the Digit Conversion Tables can be configured for use for
this CO/IP Line. eMG80/100:1-15, eMG800:1-32, UCP: 1-32
Refer to
description
DTMF tone for
Flexible button
If enabled, the system provides a DTMF tone when a user
presses the flexible button to send the DTMF tone to the called
party.
OFF
ON
OFF
Routing Attributes
Call Forward
When allowed, Call Forward can be activated by the station.
OFF
ON
OFF
DND
Enables DND to be activated by the station. The station can be
limited to activate DND for outside calls (CO/IP Only) or internal
calls (ICM only) if desired. OFF, ALL, ICM call only, CO call only
Refer to
description
OFF
