iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
65
Table 4.4.2.3-1Terminal Attributes
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
LCD Display LED
The LCD LED, upper left of LCD, may be used for intercom Call
ring Indication or both Message Wait and ring indication.
MWI/Ring,
Ring
MWI/Ring
Message Scroll
Speed
The user can adjust the scroll speed on the message from 0 to 7.
0 ~7
3
Ear& Mic Headset
The user can use Ear Microphone Headset for Internal or
external calls if the phone has the Ear. Microphone headset port.
OFF
ON
OFF
Enblock mode
When On, the user-dialed digits are stored at the iPECS IP or
LDP Phone until explicitly sent by the user. When sent, all dialed
digits are sent to the system in a block.
Enblock mode is only available to iPECS IP or LDP Phones
with3-Soft keys.
OFF
ON
OFF
Back Light Usage
The backlight of iPECS IP and LDP Phones is assigned to stay
off, light only when the station is busy, or light constantly. Please
check the phone if the feature is available before setting this
option. Always Off, Busy Only, Always On
Refer to
description
Busy Only
By Pass DTMF
When detected, DTMF from an SLT may be regenerated by
CO/IP Line interface circuitry. The SLT port can bypass
detection, so DTMF is not detected.
OFF
ON
OFF
Serial DSS Usage
Enables a LIP-8000/LIP-9000/1000i station to have a Serial
DSS/BLF Console attached.
Disable
Enable
Enable
Howler Tone
Howler tone can be sent to a phone when left off-hook.
OFF
ON
ON
Flex Button Page
LDP-9240D,LIP-9030/9040(C), LIP-9071, 1020i, 1030i, 1040i,
1050i,1080ihas flexible button page in LCD. (Max: LIP-
9071,1080i: 4, LIP-9030/9040(C)/1020i/1030i/1040i/1050i : 3,
LDP-9240: 2)
The Navigation Up/Down button is used to scroll through the Flex
buttons pages assigned.
Use 1 Page, Use 2 Page, Use 3 Page, Use 4 Page
Refer to
description
Use 3
Page
Default flexible
button page
The flexible button page automatically goes to a predefined page
when the phone goes idle.
Use 1 Page, Use 2 Page, Use 3 Page, Use 4 Page
Refer to
description
Use 1
Page
Align LCD
For the iPECS LIP-9010/20/30/40, character alignment for
messages to the phone can be right or left aligned by the system
or alignment controlled by the phone (“Not Align”).
For the other phone, please check if the feature is available
before using this option.
Not Align
Align Left
Align Right
Not Align
Small Popup Use
If this option is set to ON, small popup is displayed on the LCD of
LIP-9030/9040/1010i/1020i/1030i/1040i/1050i.
If it is set to OFF, the top bar is displayed instead of a small
popup.
OFF
ON
OFF
