5-116
20. Loosen the screw (B), stretch the Scraper and align the right edge to the right end. Gently
tighten the screw (B).
21. Apply the toner powder (27) on the Scraper’s tip edge.
(side view)
22. Remove all the toner from the Developer Assy.
B
27
27
NOTE
Do not reuse the removed toner.
