K117sm5e9
5-131
59. On the machine right side (left hand grip side)
, remove the Seal 27 (98), the Seal 28 (99) (100),
the Seal 29 (101) and the Seal 30 (102) from the inner face of the Developer side plate (103).
See step 44-53 for reference to apply the new Seal 27, Seal 28, Seal 29, Seal 30, Double-
sided Tape 2 onto the Side Plate 18.
(Read with replacing “right and left” in the example figures)
103
98: lower layer
99
102
100
101
To Next Page
