Lexmark X862de User Manual

2-128 MFP Service Manual
7500-432, -632, and -832
Go Back
Previous
Next
842.10 Scanner unit assembly - ADF communication failure
842.11 Scanner communication failure (by scanner)
4 Perform a POR.
Does the error remain when the power is turned off/on again?
Replace the RIP
card assembly.
Go to “RIP card
assembly
removal” on
page 4-130.
Problem solved.
Step Check Yes No
1 Check all connections of the scanner controller card
assembly.
Are the connections of the scanner controller card assembly
connected properly?
Go to step 2. Replace all
connections.
2 Check all connections of the ADF controller card assembly.
Are the connections of the ADF controller card assembly
connected properly?
Go to step 3. Replace all
connections.
3 Perform a POR.
Does the error remain when the power is turned off/on?
Replace the ADF
controller card
assembly.
Go to “ADF
controller card
assembly
removal” on
page 4-175.
Problem solved.
4 Perform a POR.
Does the error remain when the power is turned off/on?
Replace the
scanner controller
card assembly.
Go to “Scanner
controller card
assembly
removal” on
page 4-151.
Problem solved.
Step Check Yes No
1 Check all connections of the scanner controller card assembly.
Are the connections of the scanner controller card assembly
connected properly?
Go to step 2. Replace all
connections.
2 Check all connections of the ADF controller card assembly.
Are the connections of the ADF controller card assembly
connected properly?
Go to step 3. Replace all
connections.
Step Check Yes No

Lexmark X862de Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	50 ppm
Print Resolution	1200 x 1200 dpi
Copy Speed (Color)	50 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Fax Speed	33.6 kbps
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi
Display	7-inch color touchscreen
Operating System Compatibility	Windows, Mac, Linux
Recommended Monthly Page Volume	5, 000 pages
Paper Capacity	650 sheets
Media Sizes Supported	A4, A5, Legal, Letter, Executive
Scanner Type	Flatbed, ADF
