4-274
MFP Service
Manua
l
7500-4
32, -
632, a
nd -832
Go B
ac
k
Previous
Next
2000-s
hee
t dual inpu
t (TT
M)—pick
roll drive
gear 25
tooth re
moval
1.
Remove the media tr
ay assemb
ly.
2.
Remove the pick ro
ll. See
“2000-
sheet dual i
nput (TTM)—pic
k
r
oll remova
l” on page
4-273
.
3.
Remove the pick ro
ll drive gea
r 25 tooth (A).
A
Front
B
653
655
