3 - 19
Chapter 3 Removal and Replacement Procedures (RRPs)
10) With completely opened GUIDE ASSEMBLY SD L150 (PL 2.1) and GUIDE ASSEMBLY SD R150
(PL 2.1), install the GEAR PINION (PL 2.1) to the HOUSING TOP 150.
When installing the GEAR PINION, make sure the GUIDE ASSEMBLY SD R150 and
GUIDE ASSEMBLY SD L150 are completely opened. If not, the side register may be mis-
aligned.
11) Install the COVER CST (PL 2.1) to the 150 PAPER CASSETTE.
To Next Page
