3 - 208
Chapter 3 Removal and Replacement Procedures (RRPs)
When installing the GEAR 19, be careful in the installing direction.
4) Install the BRACKET MOTOR OCT (PL 11.1) using the 2 screws (gold tapping, 8mm).
5) Install the SUPPORT OCT LEFT using the 2 screws (gold tapping, 8mm, gold 6mm).
6) Install the COVER OCT (PL 11.1). (RRP11.4)
7) Install the COVER REAR (PL 11.1). (RRP11.2)
To Next Page
