3 - 226
Chapter 3 Removal and Replacement Procedures (RRPs)
6) Connect the connector (P/J855) of the HARNESS ASSY CLSNR1 (PL 12.2.31) to the HAR-
NESS ASSY CLSNR2 (PL 12.1.36).
After connecting the connector, put the connector under the harness.
7)Install the COVER RE550 (PL 12.1.25) to the frame using the 5 screws (gold tapping,
8mm).
To Next Page
