Chapter 3 Removal and Replacement Procedures (RRPs)

SPRING BTM LOCK

(PL20.3.24)

LEVER BTM LOCK

(PL20.3.27)

STOPPER GEAR

(PL20.3.29)

GEAR LEVEL LOCK

(PL20.3.26)

GEAR BTM LOCK PINION

(PL20.3.23)

GEAR BTM LOCK

(PL20.3.25)

RACK BTM LOCK 550

(PL20.3.21)

COVER BTM UP 550

(PL20.3.22)

SPRING STOPPER GEAR

(PL20.3.28)

PLATE GEAR LOCK 550

(PL20.3.19)

GEAR PB R

(PL20.3.20)

NOTE1)

STOPPER

LEVER BTM LOCK

(PL20.3.27)

STOPPER GEAR

(PL20.3.29)

JG3535AB

SEE NOTE2
