4.2 DIP SW, LED, VR, TP, AND FUSE TABLES
4.2.1 TEST POINTS
MPU
No Usage
TP101
TP102
TP103
TP104
TP105
TP106
TP107
TP108
TP109
TP110
CIS Sample Clock
Video Signal
GND-a
Scan Line Synchronizing Signal
Ink Detection Pulse (Standard Pulse)
Ink Detection Pulse
Not used
Master End Sensor Output Voltage
GND-a
-12V
4.2.2 POTENTIOMETERS
MPU
No Usage
VR101
VR103
Ink Detection Adjustment
Master End Sensor Adjustment
Power Supply Unit
No Usage
VR2 Thermal Head Voltage Adjustment
4.2.3 LED'S
MPU
LED # OFF ON
101 Low Ink Condition Sufficient Ink Condition
