MASTER EJECT SECTION
6-24
C231/C237/C238 SM
6.6 MASTER EJECT SECTION
6.6.1 MASTER EJECT UNIT REMOVAL
1. Turn off the main switch and disconnect the power plug.
2. Remove the 2 screws [A].
3. Pull out the master eject unit.
4. Remove the 2 screws [B].
C231R523.WMF
[B]
[A]
[B]
