SP TABLE (SP 6-XXX)
SM 5-11 C267
C267 Service
Manual
5.7 ADJUSTMENT
5.7.1 SP TABLE (SP 6-XXX)
No. Menu Items Default Settings
1 Main-scan position – platen 0 -5.0 to 5.0 mm
2 Main-scan position – ADF 0 -5.0 to 5.0 mm
3 Scan start position – platen 0 -2.0 to 5.0 mm
4 Scan start position - ADF 0 -5.0 to 5.0 mm
5 Scanning speed - platen 0 -5.0 to 5.0 %
6 Scanning speed - ADF mode 0 -5.0 to 5.0 %
10 Master writing speed 0 -5.0 to 5.0 %
11 Master writing length 0 -5.0 to 5.0 %
20 Registration buckle 0 0 to100 PLS
21 Paper regist position 0 -5.0 to 5.0 mm
27 Master making density - Tint 1 0: Pale, 1: Normal, 2: Dark
28 Master making density - Photo 1 0: Pale, 1: Normal, 2: Dark
29 Master making density - Letter/Photo 1 0: Pale, 1: Normal, 2: Dark
30 Master making density - Letter 1 0: Pale, 1: Normal, 2: Dark
32 MTF filter – Letter: Main 2 0 to 7
33 MTF filter – Letter: Sub 2 0 to 7
34 MTF filter – Letter/Photo: Main 2 0 to 7
35 MTF filter – Letter/Photo: Sub 2 0 to 7
36 MTF filter - Photo: Main 2 0 to 7
37 MTF filter – Photo: Sub 2 0 to 7
40 Ink detection adjustment –
50 Master end sensor voltage 2 0.5 to 3.5V
61 Master length – LG drum 4780 4200 to 6000 (0.1mm)
62 Master length – B4 drum 4780 4200 to 6000 (0.1mm)
63 Master length – A4 drum 4140 3000 to 6000 (0.1mm)
70 SBU VRT value –
71 SBU FBO value –
72 SBU FBE value –
100 Paper registration 30rpm 0 -40 to 40
101 Paper registration 60rpm 0 -40 to 40
102 Paper registration 80rpm 0 -40 to 40
103 Paper registration 100rpm 0 -40 to 40
104 Paper registration 130rpm 0 -40 to 40
108 Paper regist: skip: 30rpm 0 -40 to 40
109 Paper regist: skip: 60pm 0 -40 to 40
