MECHANICAL COMPONENT LAYOUT
SM 6-1 C267
C267 Service
Manual
6. DETAILED SECTION DESCRIPTIONS
6.1 MECHANICAL COMPONENT LAYOUT
1. Tension Roller
2. Master Feed Roller
3. Platen Roller
4. Thermal Head
5. Master Roll
6. Paper Feed Roller
7. Paper Pick-up Roller
8. Paper Table
9. Registration Rollers
10. Doctor Roller
11. Press Roller
12. Ink Roller
13. Vacuum Fan Motor
14. Exit Pawl
15. Transport Belts
16. Paper Delivery Table
17. Air Knife Fan Motor
18. Master Eject Box
19. Master Eject Rollers
20. 3
rd
Mirror
21. 2
nd
Mirror
22. 1
st
Mirror
23. DF Exposure Glass
24. 1
st
Transport Roller
25. Separation Roller
26. Original Feed Belt
27. Pick-up Roller
28. 2
nd
Transport Roller
29. Original Exit Roller
C267D004.WMF
1011121314 15 16
17
19
18
20
21
22
29
24
28
26
27
25
23
1
2
3
5
4
6
7
8
9
