MASTER FEED
SM 3-15 C267
C267 Service
Manual
3.5 MASTER FEED
3.5.1 MASTER MAKING UNIT
[A]: Master making unit cover ( x 3)
[B]: Master making unit ( x 2,  x 4, = x 1,  x 1))
3.5.2 MASTER MAKING UNIT SET SWITCHES
z Master making unit ( 3.5.1)
[A]: Master making unit set switch ( x 1,  x 1)
C267R016.WMF
C267R036.WMF
[A]
[B]
[A]
