Ricoh C231 - Main Body and Peripherals

INSTALLATION REQUIREMENTS
SM 1-3 C267
C267 Service
Manual
1.1.6 MAIN BODY AND PERIPHERALS
This is a list of the peripheral devices that can be installed with the digital duplicator.
No. Model Name Comments
1 C267 Digital duplicator Main Machine
2 C642 ADF Auto document feeder
3 B406 Platen cover
4 C643/C647/C648 Color drum Optional drum – A4/LG/B4
5 C651 Tape Dispenser
6 C646 Printer unit VC-20 Printer controller unit
C267I159.WMF
1
2 3
4
5
6
