4.2.4 FUSES
MPU
FUSE #
Rated
Current
Voltage Related Devices
101 1 A 24VDC Paper Transport Motor
102 1 A 24VDC Ink Pump Motor, Master Eject Motor
PSU
FUSE #
Rated
Current
Voltage Related Devices
501 10 A 120/230VAC AC Line
502 5 A 24VDC Paper Transport Motor, Paper Feed Clutch,
Air Knife Fan Motor, Front/Rear Pressure
Release Solenoid, Vacuum Fan Motor
503 5 A 24VDC
Ink Pump Motor, Master Eject Motor,
Optional Key Counter, Master Counter,
Paper Counter, Contact Image Sensor
504 6.3 A 24VDC Main Motor Control Board
505 5 A 24VDC Optional Tape Dispenser
