INSTALLATION PROCEDURE
C231/C237/C238 1-14 SM
ADF stabilizer installation
1. Attach the two stabilizer brackets [A] to the back of the table using the
thumbscrews (4 screws).
2. Attach the caution label [B], as shown.

CAUTION
This procedure must be done to prevent the machine from falling
backwards when the ADF is open.
C238I040.WMF
[A]
[B]
