2.2 IMAGE-PROCESSING
2.2.1 OVERVIEW
This model uses a contact image sensor (CIS) instead of a CCD. It removes the
necessity for the complicated adjustments that are needed for a CCD scanner.
There are three main chips on the main processing unit (MPU) as shown. The
halftone processor chip enables the use of Letter/Photo mode in addition to Letter
and Photo modes. In Letter/Photo and Photo modes, error diffusion processing
produces better copy quality halftone images.
The halftone processor also includes the A/D conversion function, as well as the
image processing functions. The thermal head drive function is built into a chip
(GA2) on the MPU.
A/D
