Ricoh C231 - Air Knife

6.10.3 PAPER SEPARATION FROM DRUM
Air knife
• The air from the air knife fan motor [A] separates the paper from the drum.
• The air knife fan motor starts blowing air when the print start key is pressed or
when master cutting is finished. The paper passes under the exit pawl and is
delivered to the delivery table.
C267D022.WMF
[A]
