TAPE CUT LENGTH ADJUSTMENT
7-7
Tape Marker
C532
C532 SM
3.3 TAPE CUT LENGTH ADJUSTMENT
Adjustment standard : 250 mm ± 15 mm
1. Turn on the main body and the tape dispenser main switches.
2. Press the manual cut switch [A].
NOTE: Do not press the switch longer than 2.5 seconds.
3. Measure the tape length.
If the tape is longer than 250 mm, turn VR2 [B] counterclockwise.
If the tape is shorter than 250 mm, turn VR2 clockwise.
!
CAUTION
Do not turn VR1. It is for factory adjustment only.
C532R504.PCX
[A]
[B]
To Next Page
