Ricoh C231 - Drive Layout

DRIVE LAYOUT
1-17
SM C231/C237/C238
Overall
Information
1.6 DRIVE LAYOUT
1. Pressure Plate Motor
2. Clamper Motor
3. Paper Transport Motor
4. Main Motor
5. Registration Motor
6. Paper Table Motor
7. Paper Feed Clutch
8. Master Feed Motor
C231V501.WMF
1
3456
7
8
2
