Ricoh C231 - Dimensions; Minimum Space Requirements

INSTALLATION REQUIREMENTS
C267 1-2 SM
1.1.4 MINIMUM SPACE REQUIREMENTS
Place the machine near a power source, providing minimum clearance as shown
below.
1.1.5 DIMENSIONS
C267I156.WMF
C267I904.WMF
C267I158.WMF
750 mm (29.5")
686 mm (27.0")
with ADF
633 mm (24.9")
1224 mm (49.0")
663 mm (26.6")
600 mm (23.6") Left
200 mm (7.9") Rear
600 mm (23.6") Right
600 mm (23.6") Front
