Ricoh C231 - Delivery Belt; Paper Exit Sensor; Paper Delivery Unit

Replacement
Adjustment
PAPER DELIVERY
SM 3-29 C231/C237/C238
3.9 PAPER DELIVERY
3.9.1 PAPER DELIVERY UNIT
[A]: Paper delivery cover (

x 4)
[B]: Paper delivery unit (

x 3,

x
2)
3.9.2 DELIVERY BELT / PAPER EXIT SENSOR
•
Paper delivery unit (

3.9.1)
[A]: Paper guide (

x 2)
[B]: Delivery belts
[C]: Vacuum fan motor (

x 1,

x 4)
[D]: Paper exit sensor (

x 1)
C238R027.WMF
C238R036.WMF
C238R035.WMF
[A]
[B]
[C]
[D]
[A]
[B]
