Ricoh C231 - Main Motor Pulley Position

MAIN DRIVE
SM 3-65 C267
C267 Service
Manual
3.11.3 MAIN MOTOR PULLEY POSITION
After putting the pulley back on the main motor shaft, refer to the above illustration
for the correct position of the pulley.
Standard: 46.3 ±0.3 mm
NOTE: Tight the screws alternately little by little. Do not tighten them completely
one by one.
C267R033.WMF
[A]
46.3±0.3 mm
